Linux file structure – comparsion with Windows

Here is the Linux file structure from the root, which some explanations. The main explanation for the /bin, /boot /lib are the basic files that are required on boot up that the kernel needs to “run” as such. The files within the /usr are the files that user programs use e.g. games.

Anyway here is a list of directories on my linux setup.

bin binary files for boot up e.g. mount e.g.
boot boot files – kernel images etc.
dev devices on the computer.
etc configuration files for the programs
home home users, e.g. your name /home/ian
lib libraries
lib32 libraries for the 32bit programs
lib64 /lib (link to the libraries since I am using the 64 linux version)
lost+found
media media that is going to be mounted (cd-rom’s)
mnt media that is going to be mounted (Hard drives etc)
opt opitional programs e.g. things like google chrome, they are normally place in here is not distro specific.
proc processes that are happening on the computer, all process you can “talk” to
root root home files.
sbin sbin, booted up at initial stage of the boot process, things like modprobe for setting up systems items.
sys system image of devices attached and also file systems that are loadable.
tmp tempoary files.
usr user files, e.g. games, libraries, binary files
bin games include lib lib32 lib64 local sbin share src
it has its own includes, libraries, sbin and bin directories for all of the files within that user directory.
var variable files, e.g. logs, apache www hosting files.

The Windows equivalent would be that most of the / (root) directory is within the c:/windows directory, apart from the /home which is the c:/Users or c:/Documents depending on your Windows version.

bin /Windows /Windows/System32 /Windows/System
boot boot.ini file that points to what to do.
dev Does not appear to have something similar on the file system
etc /Program Data (depending on Windows versions)
home /Users
lib /Windows /Windows/System32 /Windows/System /Windows/.Net (for .Net stuff) etc.
lib32
media Does not appear to have a link to the different mount points but display them on the windows explorer
mnt Does not appear to have a link to the different mount points but display them on the windows explorer
opt /Program files/
proc Does not appear to have a list of running process on the file system, but you can view them with pslist pskill
root /Documents/Admin user account
sbin /Windows
sys Does not appear to have a list of devices attached
tmp /tmp
usr /Program files/
var /Program files/ or where ever you want them.

That kinder helps me to understand that there is more details on the command line, directory structure to actual processes and devices attached than Windows, well of course there is the regviewer that can display options like the /etc in the linux but nothing as structured, things just across like a mess (to me anyway).

SugarCRM hook – what are they

SugarCRM is a very nice and open source CRM (Customer relationship management) system. And with being open source means that you are able to alter the internals of it and also are able to write modules for it easier than closed source applications because you can follow the direction of things if you are for example debugging etc.

The hooks part of the sugarCRM setup allows to place your own code into the base code at set parts of execution e.g. after retrieve of data, or post processing of data updates.

Here is a link to the sugarcrm site of hooks definitions. Basically there is 3 main types, with subhooks attached to those types.

  • Application hooks
    • after_ui_frame – Fired after the frame has been invoked and before the footer has been invoked
    • after_ui_footer – Fired after the footer has been invoked
    • server_round_trip – Fired at the end of every SugarCRM page
  • Module hooks
    • before_delete – Fired before a record is deleted
    • after_delete – Fired after a record is deleted
    • before_restore – Fired before a record is undeleted
    • after_restore – Fired after a record is undeleted
    • after_retrieve – Fired after a record has been retrieved from the database. This hook does not fire when you create a new record.
    • before_save – Fired before a record is saved.
    • after_save – Fired after a record is saved.
    • process_record – Fired immediately prior to the database query resulting in a record being made current. This gives developers an opportunity to examine and tailor the underlying queries. This is also a perfect place to set values in a record

Constant casting

Constant casting is when you are for example calling a external library function that does not understand the const (constant) type and so you will need to take it off because the program will do something funny otherwise, crash. etc..

Here is a example code of a const_cast

#include <iostream>

using namespace std;

int exampleextenalfuction(int value)
{
	// you can alter the value if you want to, since it is not longer a constant value
	return value  + value;
}

int main()
{
	const int constvalue = 2;

	cout << constvalue << endl;

	cout << "Calling a external function that does not use constant types" << endl;

	cout << exampleextenalfuction(const_cast<int&>(constvalue)) << endl;
}

Static casting

Static casting is when you want to convert one type into another, static casting is used allot of the time without even knowing. For example

int value = 2;
float t = float(value);

the float(value) is a static casting of converting one value into another. Below is a full code example

#include <iostream>

using namespace std;
int main()
{
	int i = 3;
	// the float(<value)> is basically a static cast from a interger value into a float
	cout << float(i) << endl;
	cout << static_cast<float>(i) << endl;
}

It is very small since static_cast’ing is very basic in nature, but the only problem is that you have to check to make sure that there is a error e.g not NULL.

Execution order

Execution order of programs code is very much a vital thing to understand and where some fault finds will take a long while to figure out. Basically like in maths where there is a order of calculating, well in coding structures and also multitasking and multi-threading setups the execution order may be incorrect for lines of code.

Here is some examples, the first is when will a function be called and the later when post/pre incrementation will take place.

#include <iostream>

using namespace std;

int value =1;

int setvalue2()
{
	cout << "setting value"<<endl;
	value = 2;
	return value;
}

int returnvalue()
{
	cout << "renting value"<< endl;
	return value;
}

int main()
{
	// depending on the order of execution the value may be
	/* setvalue2 called first
		(setvalue2 = 2 / returnvalue = 2) = 1
	   returnvalue called first
		(setvalue2 = 2 / returnvalue = 1) = 2
	*/
	cout << setvalue2() / returnvalue() << endl;

	int i;
	i = i++ - ++i;	// not sure what i will be because the pre/post increaments
	i = 3, i++, i++; // i will equal 5 because in correct order.
}

Dynamic Casting

Dynamic casting, means that you can convert one object into another that is off the same type. For example, if you had a base class called Shape and a inherited class called Rectangle then you are able to convert a Shape object into a Rectangle.

Rectangle *rec = dynamic_cast<Shape *>(shapeobject);

sort of thing, there has to be a virtual function within the base class otherwise the compiler will complain, but apart from that that is about it.

Dynamic casting allows for NULL returns which is the best thing, because you can test to see if the casting actually worked and not to do anything silly on a NULL object which would crash the program.

Pointer casting uses the sytnax

<type> *p_subclass = dynamic_cast<<type> *>( p_obj );

Reference will not throw an error/expcetion so will need to check std::bad_cast< typeinfo header >, here is the syntax

<type> subclass = dynamic_cast<<type> &>( ref_obj );

Hopefully this will make more sense for how and why it works.

#include <iostream>

using namespace std;

class classA
{
	public	:
		int x;		// should be private
		char y;		// should be private

		classA();

 		virtual ~classA() {}; 	// need to have a virtual function for dynamic casting
};

// basic classA constructor
classA::classA()
{
	cout << "classA" << endl;
	x = 1;
	y = 'a';
}


class classB : public classA
{
	public :
		int b;		// should be private

		classB();

		~classB() {};	// complete the virtual
};

// basic classB constructor
classB::classB()
{
	cout << "classB" << endl;
	x = 2;
	y = 'b';
}

int main()
{
	classA newa;	// classA obj
	cout << "class A constructed" << endl;
	classB newb;	// classB obj
	cout << "class B constructed" << endl;

	cout << "NewA X " << newa.x << endl;
	cout << "NewB X " << newb.x << endl;

	// point a classB to a already created classB object
	classB *normalB = &newb;
	// dynamic_cast a normalB object (newb) to another classA object
	classA *dynA = dynamic_cast<classB *>(normalB);
	cout << "dynamic A X " << dynA->x << endl;

	// does not work, because you cannot convert classA into a classB, but if classA was pointing to a classB type.
	classA *normalA = &newa;
	classB *dynB = dynamic_cast<classB *>(normalA);
	if (dynB)	// above produces a 0 because invalid.
	{
		cout << "dynamic B X " << dynB->x << endl;
		cout << "dynamic B X " << dynB->b << endl;
	}

	// this does work because it is converting from a pointer of classB type, which was "sitting" in a classA container
	// and then is converted back to a classB
	classA *normalA2 = &newb;
	classB *dynB2 = dynamic_cast<classB *>(normalA2);
	if (dynB2)	// above produces a 0 because invalid.
	{
		cout << "dynamic A2X " << normalA2->x << endl;	// output is 2 because it was a classB constructed
		cout << "dynamic B X " << dynB2->x << endl;
		cout << "dynamic B X " << dynB2->b << endl;
	}

}

Grab data from tables

Alter the variable @tableName to the table and also the @tableWhere for the where condition, I found that if you use the standard sql dumps that you was taking allot of other crap with you as well.

The code

DECLARE @colName VARCHAR(100), @colSql VARCHAR(500), @colSQLInsert VARCHAR(500), @TYPE INT, @auto INT, @tableName VARCHAR(50), @tableWhere VARCHAR(500);
SET @tableName = 'tablename';
SET @tableWhere = 'the where condition';

-- grab the table column names
DECLARE tablecol cursor FOR
SELECT name, typestat, autoval FROM syscolumns WHERE id = (SELECT id FROM sysobjects WHERE name = @tableName);

--The @auto is the auto generated fields e.g. primary key. </b>
SET @colSql = '';
SET @colSQLInsert = '';
OPEN tablecol;
fetch tablecol INTO @colName, @TYPE, @auto;
while (@@fetch_status = 0)
BEGIN
       IF (@auto IS NULL)
       BEGIN
              IF (charindex('.',@colName) > 0) SET @colName = '['+@colName+']';
              SET @colSQL = @colName + ',' +@colSQL;
              IF (@TYPE = 2)
                     SET @colSQLInsert = '''''''+isnull(' + @colName + ',0)+'''''',' + @colSQLInsert;
              ELSE
                     SET @colSQLInsert = '''+str(isnull(' + @colName + ',''''))+'',' + @colSQLInsert;
       END
       fetch NEXT FROM tablecol INTO @colName, @TYPE, @auto;
END
close tablecol;
deallocate tablecol;
-- to build the sql statement, since it stops at 255 charactes split the outputs</b>
SELECT 'select (''insert into '+@tableName+' (';
DECLARE @loopingVal INT;
SET @loopingVal =0;
while (len(@colSQL) > @loopingVal)
BEGIN
       SELECT SUBSTRING(@colSQL, @loopingVal, 255);
       SET @loopingVal = @loopingVal + 255;
END
SELECT ') values (';

SET @loopingVal =0;
while (len(@colSQLInsert) > @loopingVal)
BEGIN
       SELECT SUBSTRING(@colSQLInsert, @loopingVal, 255);
       SET @loopingVal = @loopingVal + 255;
END
SELECT ')'') from '+@tableName + ' ' + @tableWhere;

The output will be x lines, and if you just copy them into a single line and this will display (once executed) the insert lines.

If anyone has any better methods, please comment 🙂
